As a welding Fixture/welding station/welding line/welding fixture stand manufacturer, we would like to share that what is the role of Welding Fixtures in machining?

First of all, what is the basic function of the automation welding fixture ?
The basic function of welding jig&fixtures in machining is to ensure the relative positional accuracy of parts. After using the fixture that can be directly positioned, not only the machining accuracy is much higher than that achieved by marking and alignment, but also stable and reliable. Choosing the right fixture can improve production efficiency and reduce processing costs. In addition, the fixture also has the function of improving the working conditions of the operator.

Second, what is the fundamental role of the jig and fixture for welding?
The most fundamental purpose of using fixtures is to achieve the purpose of improving product productivity and obtaining better economic benefits under the premise of ensuring the quality of product parts is stable and meeting technical requirements. Therefore, designing automated welding fixtures is not only a technical issue, but also an economic issue. Whenever a set of fixtures is designed, necessary technical and economic analysis must be carried out to obtain better economic benefits for the designed fixtures.
The above analysis shows the importance of fixtures in machining, so technicians have always regarded fixture design and improvement as an important content in technological innovation.
but! Under the production scale and different production conditions, the function of the fixture is also emphasized, and the complexity of its structure is also very different.
①Under the condition of single piece and small batch production, it is suitable to use universal adjustable fixture. In order to expand the process range of the machine tool and change the use of the machine tool, some special fixtures can be used, and the structure is also simple.
②If it is in mass production, or under the condition of small batch production all year round, the function of the fixture is mainly to improve the productivity under the premise of ensuring the machining accuracy. Therefore, it is necessary to improve the structure of the fixture. It has been improved, the product quality is stable, and the economic benefits can still be guaranteed.
The above is all there are to share this article, we hope it can help the readers!
